24" Wide Built-In Refrigerator-Freezer, ADA Compliant - CT663BKBIFRADA

24" Wide Built-In Refrigerator-Freezer, ADA Compliant

Model: CT663BKBIFRADA

24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA
24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA
24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA
24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA
24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA
24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA
+3more

Color : Other

24" Wide Built-In Refrigerator-Freezer, ADA Compliant CT663BKBIFRADA
Other

Key Features

  • ADA compliant

  • Built-in capable

  • Slim undercounter dimensions

  • Stainless steel door frame

  • Pro style handle

  • Cycle defrost

  • Dual evaporator

  • Adjustable glass shelves

Read More

Available from Mr. Appliance, serving customers throughout "Georgia and Central Florida".

Features
Specifications

Features

ADA compliant

32" high to fit under lower ADA compliant counters

Built-in capable

Make the best use of space by installing your appliance under the counter

Slim undercounter dimensions

Less than 24" wide with a generous storage capacity

Stainless steel door frame

Two-piece "U"-shaped door frame accepts slide-in custom panels (panel size: 23" W x 28" H at up to 1/4" thick)

Pro style handle

Stainless steel handle adds an attractive touch

Cycle defrost

This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment

Dual evaporator

Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators

Adjustable glass shelves

Rearrange refrigerator space to accommodate all sizes or remove shelves for simple cleanup

Door storage

Store tall bottles and condiments right on the door for convenient access

Wine shelf

Removable scalloped wine shelf is included to store champagne and wine bottles

Clear crisper drawer

Get the longest life and best taste out of produce by storing greens in a bottom crisper

Interior light

Automatically illuminates when you open the door

Hidden evaporator

Cold wall design with hidden evaporator creates a seamless, easy to clean interior

Adjustable thermostat

Dial thermostat located inside for easy temperature management

Reversible door

User-reversible door swing for added flexibility

Fully finished black cabinet

Allows the unit to be used freestanding

100% CFC Free

Environmentally friendly design with no ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Specifications

Dimensions & Weight

Width23.63 in.
Height32 in.
Length23.5 in.
Weight100 lbs.

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement10.28 ft³
Dimensional Weight127.84 lbs.
Total of Cubes10.28 ft³
Total of Dimensional Weight127.84 lbs.

Overview Refrigerator-Freezer

Height of Cabinet32.0" (81 cm)
Height to Hinge Cap32.38" (82 cm)
Width23.63" (60 cm)
Depth23.5" (60 cm)
Depth with door at 90°45.38" (115 cm)
Capacity5.1 cu.ft. (144 L)
Defrost TypeCycle
DoorPanel-Ready
CabinetBlack
US Electrical SafetyETL
Canadian Electrical SafetyETL-C
Energy Usage/Year365.0kWh/year
Amps1.4
Voltage/Frequency115 V AC/60 Hz
Weight100.0 lbs. (45 kg)
Parts & Labor Warranty1 Year
Compressor Warranty5 Years
UPC761101068534
Door SwingRHD
ReversibleYes
Adjustable ShelvesYes
Crisper Qty1
Crisper FinishTransparent
Crisper CoverGlass
Wine Bottle ShelvingYes
Interior LightYes
Refrigerator - Interior Height18.0" (46 cm)
Refrigerator - Interior Width21.0" (53 cm)
Refrigerator - Interior Depth18.0" (46 cm)
Refrigerator - Capacity4.5 cu.ft
Refrigerator - Shelf TypeGlass
Refrigerator - Shelf Qty2
Refrigerator - Full Door Shelves3
Freezer - Interior Height5.25" (13 cm)
Freezer - Interior Width19.0" (48 cm)
Freezer - Interior Depth11.5" (29 cm)
Freezer - Capacity0.6 cu.ft
Thermostat TypeDial
Fan TypeExterior
Refrigerant TypeR600a
Refrigerant Amount0.92 oz.
High Side PSI180.0
Low Side PSI80.0
Level Legs4
Compressor Step Height5.5" (14 cm)
Compressor Step Width21.0" (53 cm)
Compressor Step Depth6.0" (15 cm)
