24" Wide 3-Drawer All-Refrigerator, ADA Compliant - SP6DBS7ADA

SummitSummit brand logo

24" Wide 3-Drawer All-Refrigerator, ADA Compliant

Model: SP6DBS7ADA

24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA
24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA
24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA
24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA
24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA

Color : Other

24" Wide 3-Drawer All-Refrigerator, ADA Compliant SP6DBS7ADA
Other

Key Features

  • Commercially approved

  • Built-in capable

  • Complete stainless steel construction

  • Slim undercounter dimensions

  • Automatic defrost

  • Fully finished cabinet

  • ADA Compliant

  • Adjustable thermostat

Read More

Available from Mr. Appliance, serving customers throughout "Georgia and Central Florida".

Features
Specifications

Features

Commercially approved

ETL-S listed to NSF-7 Standards for use in commercial establishments

Built-in capable

Make the best use of space by installing your appliance under the counter and flush with other cabinetry

Complete stainless steel construction

Built with solid durability, inside and out

Slim undercounter dimensions

Less than 24 inches wide to fit tight spaces

Automatic defrost

Reduced maintenance with auto defrost system

Fully finished cabinet

Allows the unit to be used freestanding

ADA Compliant

32 inch height is designed to fit under ADA compliant counters

Adjustable thermostat

Dial thermostat for easy temperature management

100% CFC free

Environmentally friendly design does not contain ozone-damaging chemicals

CARB Compliant

Environmentally friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Specifications

Warranty

Parts1 Year
Labor1 Year

Dimensions & Weight

Width23.75 in.
Height32 in.
Length23.5 in.
Weight120 lbs.

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement10.34 ft³
Dimensional Weight128.49 lbs.
Total of Cubes10.34 ft³
Total of Dimensional Weight128.49 lbs.

Overview Refrigerator Features Drawer Dimensions Dimensions

Height of Cabinet32.0" (81 cm)
Width23.75" (60 cm)
Depth23.5" (60 cm)
Depth with Handle23.63" (60 cm)
Depth with door at 90°39.25" (100 cm)
Capacity3.1 cu.ft. (88 L)
Defrost TypeAutomatic
DoorStainless Steel
CabinetStainless Steel
US Electrical SafetyETL
Canadian Electrical SafetyETL-C
SanitationETL-S
Amps1.2
Weight120.0 lbs. (54 kg)
Parts & Labor Warranty1 Year
Compressor Warranty5 Years
UPC761101069531
Thermostat TypeDial
Fan TypeInterior and Exterior
Refrigerant TypeR600a
Refrigerant Amount0.64oz.
High Side PSI180.0
Low Side PSI80.0
Level Legs Qty4
Interior Height 16.25" (16 cm)
Interior Width 118.63" (47 cm)
Interior Depth 111.5" (29 cm)
Interior Height 26.25" (16 cm)
Interior Width 218.63" (47 cm)
Interior Depth 216.0" (41 cm)
Interior Height 36.25" (16 cm)
Interior Width 317.25" (44 cm)
Interior Depth 316.0" (41 cm)
Compressor Step Height7.0" (18 cm)
Compressor Step Width18.63" (47 cm)
Compressor Step Depth6.0" (15 cm)
