30" Free-Standing Gas Range - RGB745BEAAD

HotpointHotpoint brand logo
This product has been discontinued by the manufacture and is no longer available.

30" Free-Standing Gas Range

Model: RGB745BEAAD

30" Free-Standing Gas Range RGB745BEAAD30" Free-Standing Gas Range RGB745BEAAD
30" Free-Standing Gas Range RGB745BEAAD
30" Free-Standing Gas Range RGB745BEAAD

Color : Almond

product image
Almond

Type : Gas

GasElectric

Key Features

  • Self-clean oven

  • Super-large oven capacity

  • Sealed cooktop burners

  • Performance plus burner

  • Simmer burner

  • All purpose burners

  • EasySet III controls

Available from Mr. Appliance, serving customers throughout "Georgia and Central Florida".

Features
Specifications
Certifications

Features

Self-clean oven

Conveniently cleans the oven cavity without need of scrubbing

Super-large oven capacity

Provides an impressively large oven interior for cooking more dishes and large meals at once

Sealed cooktop burners

Eliminate the space between the burners and the cooktop to help contain spills and boil over liquids, ensuring easy cleanup

Performance plus burner

Provides a maximum output of 12,000 BTUs for fast heat-up and boiling

Simmer burner

Provides low, even heat distribution for delicate foods and sauces

All purpose burners

Deliver a wide range of heat output ideal for most cooking needs

EasySet III controls

Features a smooth glass design that's easy-to-operate and easy-to-clean

Certifications

California Prop 65 certification

California Prop 65

Specifications

FEATURES

ConfigurationRange with Storage Drawer
Cleaning TimeVariable
Ignition SystemElectronic
Interior Oven LightYes
Fuel TypeNatural Gas
Oven Control FeaturesOven "ON" Light
Cooktop Burner TypeSealed
Oven Rack FeaturesEmbossed Rack Positions
Clock and Minute TimerEasySet III
Oven Cleaning TypeSelf-Clean
All-Purpose Burners(2) 9,500/850 BTU
Performance Plus Burner(1) 12,000/2,200 BTU
Cooktop Burner Grate MaterialHeavy Steel
Valves (Degree of Turn)270
Simmer Burner(1) 5,000/600 BTU
Cooktop SurfacePorcelain-Enamel
Oven Rack Positions (Single or Upper/Lower)6
Leveling System4 Leveling Legs
Control TypeEasySet IV
One-Piece Drip PansBlack Porcelain-Enameled

APPEARANCE

Cooktop Burner Grate ColorBlack
Oven Door FeaturesOven Window
HandleDesigner Style
Frameless Oven Door(s)Black Glass
Color AppearanceAlmond

CAPACITY

Unit CapacityExtra Large Oven

ACCESSORIES

LP Conversion KitIncluded

POWER / RATINGS

Top Burner BTU Rating - Nat. Gas (000's BTU's)(1) 12.0; (2) 9.5; (1) 5.0
Electrical Requirements120V; 60Hz; 5A
Volts/Hertz/Amps120V; 60Hz; 5A
Bake/Broiler BTU Rating - Nat. Gas (000's BTU's)16.0 Bake / 13.5 Broiler

WARRANTY

Labor WarrantyLimited 1-year entire appliance
Parts WarrantyLimited 1-year entire appliance
Warranty NotesSee written warranty for full details

Dimensions & Weight

Width30 in.
Height17 in.
Length26.25 in.
Weight190 lbs.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width35 in.
Shipping Height22 in.
Shipping Length31.25 in.
Shipping Weight230 lbs.
Total of Shipping Weight230 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement7.75 ft³
Dimensional Weight96.31 lbs.
Total of Cubes7.75 ft³
Total of Dimensional Weight96.31 lbs.
