30" Free-Standing Electric Range - JBP65DMBB

GEGE brand logo
This product has been discontinued by the manufacture and is no longer available.

30" Free-Standing Electric Range

Model: JBP65DMBB

30" Free-Standing Electric Range JBP65DMBB30" Free-Standing Electric Range JBP65DMBB30" Free-Standing Electric Range JBP65DMBB
30" Free-Standing Electric Range JBP65DMBB
30" Free-Standing Electric Range JBP65DMBB
30" Free-Standing Electric Range JBP65DMBB

Color : Black

30" Free-Standing Electric Range JBP65DMBB
Black

Type : Electric

ElectricGas

Key Features

  • Super-large 5.3 cu. ft. oven capacity

  • Self-clean oven

  • QuickSet III oven controls

  • Ceramic glass cooktop

  • 9"/6" Power Boil element

  • Dual-element bake

  • Big hearth window

  • Ribbon heating elements

Description

Provides an impressively large oven interior to cook more dishes and large meals at once.Feature an easy to use design that lets you set precise cooking temperatures.46 7/8 H x 29 7/8 W x 27 3/4 D

Available from Mr. Appliance, serving customers throughout "Georgia and Central Florida".

Features
Specifications
Certifications

Features

Super-large 5.3 cu. ft. oven capacity

Provides an impressively large oven interior to cook more dishes and large meals at once

Self-clean oven

Conveniently cleans the oven cavity without the need for scrubbing

QuickSet III oven controls

Feature an easy to use design that lets you set precise cooking temperatures

Ceramic glass cooktop

A smooth cooktop surface makes cleaning quick and easy

9"/6" Power Boil element

Accommodates various-size pots or pans and 3,000 Watts of power speeds the boiling process

Dual-element bake

Alternates the upper broiling element and the lower baking element for even heating and optimal baking results

Big hearth window

Features an enhanced shape to add an elegant appearance and make viewing trouble-free

Ribbon heating elements

Provide powerful heat beneath a smooth glass surface to ensure even heat and fast warm-up times

Certifications

California Prop 65 certification

California Prop 65

Specifications

FEATURES

6"/9" Dual Heating Element1 Ribbon (3,000W Power Boil)
ConfigurationRange with Storage Drawer
Oven FeaturesDual-Element Bake
Storage Drawer FeaturesRemovable Full-Width
Interior Oven LightYes
Oven Control FeaturesVariable Broil
Oven Rack Features2 Oven Racks
Cooktop Burner TypeSmoothtop
Infinite Heat ControlsYes
6" Heating Element(s)2 Ribbon (1,500W)
Oven Cleaning TypeSelf-Clean
Hot Surface Indicator Lights1
Heating Element "ON" Indicator LightYes
Cooktop SurfacePatterned Graphite on Black Glass Ceramic
Preheated Oven LightDisplay
Control LocationBacksplash
8" Heating Element (s)1 Ribbon (2,000 watt)
Dishwasher Safe KnobsYes
Control TypeTouchpads
Cooking TechnologyTraditional
Oven Control FeaturesC° or F° Programmable
Control TypeQuickSet III
Control TypeDigiTemp Temperature Display
Cooktop Burner TypeRadiant
Cooktop SurfaceOne-Piece Upswept
Oven Control FeaturesAudible Preheat Signal
Oven Control FeaturesAuto Oven Shut-Off with Override
Oven Control FeaturesAuto Self Clean
Oven Control FeaturesElectronic Clock & Kitchen Timer
Oven Control FeaturesSelf-Cleaning Cycling Light
Oven Control FeaturesSelf-Clean Cool Down Time Display
Oven Control FeaturesOven "ON" Light
Oven Control FeaturesSabbath Mode
Oven Control FeaturesMis-Wire Detection

WEIGHTS & DIMENSIONS

Net Weight154 lb
Depth Without Handle25.375 in
Oven Interior Dimensions (W x H x D) (in.)24-1/8 x 19-1/2 x 19-3/8
Depth with Door Open47.625 in
Cabinet Width30 in
Approximate Shipping Weight175 lb
Overall Depth27 3/4 in
Overall Height46 7/8 in
Overall Width29 7/8 in

POWER / RATINGS

KW Rating at 240V11.5
Amp Rating at 208V40
KW Rating at 208V8.6
Amp Rating at 240V40

APPEARANCE

Oven Door FeaturesFrameless Lift-off Oven Door
HandleColor-Matched Sculptured
Color AppearanceBlack on Black
Oven Door FeaturesBig Hearth Oven Window
Oven Door FeaturesBlack Frameless Glass Door

CAPACITY

Unit CapacitySuper Large Oven
Total Capacity (cubic feet)5.30 cu ft

WARRANTY

Labor WarrantyLimited 1-year entire appliance
Parts WarrantyLimited 1-year entire appliance
Warranty NotesSee written warranty for full details
Warranty NotesFor models produced on or after January 1, 2006

ACCESSORIES

Cooktop CleaningSponge
Cooktop CleaningCream
Cooktop CleaningIncluded

Other

Oven Interior Dimensions (W x H x D) (in.)24-1/8 x 19-1/2 x 19-3/8

Dimensions & Weight

Width29.88 in.
Height46.88 in.
Length27.75 in.
Weight154 lbs.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width34.88 in.
Shipping Height51.88 in.
Shipping Length32.75 in.
Shipping Weight194 lbs.
Total of Shipping Weight194 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement22.49 ft³
Dimensional Weight279.57 lbs.
Total of Cubes22.49 ft³
Total of Dimensional Weight279.57 lbs.
