800 Series Gas Cooktop - NGM8656UC
800 Series Gas Cooktop
Model: NGM8656UC








800 Series Gas Cooktop
Model: NGM8656UC
Key Features
Simmer delicate sauces with the OptiSim Burner
Automatic re-ignition
Slide your pans from burner to burner
Easy to clean, low-profile design
19,000 BTU Burner: for boiling, searing, and stir-frying.
OptiSim Burner: the wide & thick burner design diffuses heat evenly and reduces hot spots -- perfect for simmering delicate sauces or melting chocolate.Close
Electronic Re-Ignition: automatically re-ignites the burner in case the flame goes out.Close
Continuous Cast Iron Grates: makes it easy to slide pots & pans from burner to burner.
Description
Documents
Available from Mr. Appliance, serving customers throughout "Georgia and Central Florida".
Features
Simmer delicate sauces with the OptiSim Burner
The OptiSim burner design is wider and thicker which diffuses heat evenly for better flame control when simmering delicate sauces.
Automatic re-ignition
The electronic re-ignition feature will automatically re-ignite the burner in case the flame goes out during use.
Slide your pans from burner to burner
The full-width continuous cast iron grate design makes sliding heavy pots easier around the cooking surface.
Easy to clean, low-profile design
The low-profile cooking surface provides a timeless, streamlined look while keeping spills contained and makes clean-up easier than ever
19,000 BTU Burner: for boiling, searing, and stir-frying.
OptiSim Burner: the wide & thick burner design diffuses heat evenly and reduces hot spots -- perfect for simmering delicate sauces or melting chocolate.Close
The OptiSim burner design is wider and thicker which diffuses heat evenly for better flame control when simmering delicate sauces.
Electronic Re-Ignition: automatically re-ignites the burner in case the flame goes out.Close
The electronic re-ignition feature will automatically re-ignite the burner in case the flame goes out during use.
Continuous Cast Iron Grates: makes it easy to slide pots & pans from burner to burner.
Easy-to-Clean: a one-piece stainless steel design makes clean-up easy.
19,000 BTU Burner:
for boiling, searing, and stir-frying.
OptiSim Burner:
the wide & thick burner design diffuses heat evenly and reduces hot spots -- perfect for simmering delicate sauces or melting chocolate.
Electronic Re-Ignition:
automatically re-ignites the burner in case the flame goes out.
Continuous Cast Iron Grates:
makes it easy to slide pots & pans from burner to burner.
Easy-to-Clean:
a one-piece stainless steel design makes clean-up easy.
OptiSim® Burner:
the wide & thick burner design diffuses heat evenly and reduces hot spots -- perfect for simmering delicate sauces or melting chocolate.
Specifications
General
| Type of Control | Front, sword knobs |
| Energy source | Gas |
| Safety | Electronic flame failure safety device |
| Total LP BTUs | 47300 Btu |
| Total NG BTUs | 58500 Btu |
| ExtraLow® Burners | no |
| ExtraLow® Burners | no |
Construction type
| Design | Built-in |
| Color of Surface | Stainless steel |
| Number of electric cooking zones | 0 |
| Number of halogen elements | 0 |
| Installation Type | Built-in |
| Type of grate | Cast iron |
| Number of electric elements | 0 |
| Total Number of Heating Elements | 5 |
| Number of radiant elements | 0 |
| Number of electric warming zones | 0 |
Cooking zone 1
| Location of heating element | front left |
| Type of heating element | Gas |
| Power of heating element (kW) | 3.52 kW |
Cooking zone 2
| Location of 2nd heating element | center left |
Cooking zone 3
| Location of 3rd heating element | back left |
| Power of 3rd heating element (kW) | 2.93 kW |
| Type of 3rd heating element | Gas |
Cooking zone 4
| Location of 4th heating element | middle back |
Cooking zone 5
| Location of 5th heating element | back right |
| Power of 5th heating element (kW) | 1.61 kW |
| Type of 5th heating element | Gas |
Cooking zone 7
| Location of 7th heating element | front right |
| Power of 7th heating element (kW) | 3.52 kW |
| Type of 7th heating element | Gas |
Cooking zone 6
| Location of 6th heating element | center right |
Cooking zone 8
| Location of 8th heating element | front middle / central |
Cooking zone 9
| Location of 9th heating element | front centre/cent |
Safety
| Residual Heat Indicator | Without |
| Type of safety device for gas | Central electronic safety device |
| Safety | Electronic flame failure safety device |
Connection
| Total connected gas load | 17,140 W |
| Location of gas connection | Bottom, Rear, Right |
| Frequency | 60 Hz |
| Energy source | Gas |
| Power Cord Length | 60'' |
| Watts | 360 W |
Accessories
| Included Accessories | 1 x nozzle set for liquid gas, 3 x cast iron pan support |
Design
| Surface Materials | Stainless Steel |
| Grate Materials | Cast Iron with Rubber Feet |
| Location of Control Panel | Front |
Comfort and Convenience
| Number of Gas Burners | 5 |
| Pedestal Star® Burners | no |
| Sealed Burners | yes |
| ExtraLow® Burners | no |
| Special Features | Reignition, Simmer Cap |
| Griddle | no |
| ADA Compliant (When Installed to ADA requirements) | no |
| OptiSim® Burner | no |
| ExtraLow® Burners | no |
Connectivity
| Home Connect™ | no |
| Home Connect™ | no |
Dimensions & Weight
| Width | 37 in. |
| Height | 3.81 in. |
| Length | 21.25 in. |
| Weight | 42 lbs. |
Number of Boxes, Shipping Dimensions, & Shipping Weight
| Number of Boxes | 1 |
| Shipping Width | 42 in. |
| Shipping Height | 8.81 in. |
| Shipping Length | 26.25 in. |
| Shipping Weight | 82 lbs. |
| Total of Shipping Weight | 82 lbs. |
| Source | Calculation |
Cubic Feet Measurement & Dimensional Weight
| Cubic Feet Measurement | 1.73 ft³ |
| Dimensional Weight | 21.57 lbs. |
| Total of Cubes | 1.73 ft³ |
| Total of Dimensional Weight | 21.57 lbs. |
