Built-In Downdraft Gas Modular Cooktop - JGP990BELBB

GE ProfileGE Profile brand logo
This product has been discontinued by the manufacture and is no longer available.

Built-In Downdraft Gas Modular Cooktop

Model: JGP990BELBB

Built-In Downdraft Gas Modular Cooktop JGP990BELBBBuilt-In Downdraft Gas Modular Cooktop JGP990BELBBBuilt-In Downdraft Gas Modular Cooktop JGP990BELBBBuilt-In Downdraft Gas Modular Cooktop JGP990BELBBBuilt-In Downdraft Gas Modular Cooktop JGP990BELBB
Built-In Downdraft Gas Modular Cooktop JGP990BELBB
Built-In Downdraft Gas Modular Cooktop JGP990BELBB
Built-In Downdraft Gas Modular Cooktop JGP990BELBB
Built-In Downdraft Gas Modular Cooktop JGP990BELBB
Built-In Downdraft Gas Modular Cooktop JGP990BELBB

Color : Black

Built-In Downdraft Gas Modular Cooktop JGP990BELBB
Black

Key Features

  • Modular cooktop options

  • Two-burner gas module

  • Downdraft exhaust

  • Sealed cooktop burners

  • Continuous grates

  • Variable 3 speed fan control

  • Upfront controls

  • Electronic pilotless ignition

Description

Shipped with unit (right bay) offers a range of temperature settings for cooking versatility.Powerful exhaust system effectively pulls smoke and steam out of the kitchen.18 1/2 H x 30 W x 21 3/4 D

Available from Mr. Appliance, serving customers throughout "Georgia and Central Florida".

Features
Specifications
Certifications

Features

Modular cooktop options

Allows the cooktop to be customized to suit individual cooking styles and tastes. Modules sold separately

Two-burner gas module

Shipped with unit (right bay), offers multiple temperature settings

Downdraft exhaust

Powerful exhaust system effectively pulls smoke and steam out of the kitchen

Sealed cooktop burners

Adhere to cooktop to help contain spills and make cleaning quick and easy

Continuous grates

Provide a flat, sturdy surface allowing easy movement of pans between burners

Variable 3 speed fan control

Powerful variable speed exhaust system that effectively pulls smoke and vapors out of the kitchen

Upfront controls

Controls are placed within easy reach at the front center of the cooktop

Electronic pilotless ignition

Provides reliable burner ignition operation, eliminating the need for a standing pilot

Certifications

ADA Compliant certification

ADA Compliant

California Prop 65 certification

California Prop 65

Specifications

WEIGHTS & DIMENSIONS

Cabinet Width30 in
Overall Width30 in
Approximate Shipping Weight74 lb
Net Weight64 lb
Overall Depth21 3/4 in
Overall Height18 1/2 in

FEATURES

Removable Grease Filter(s)Yes
Dishwasher Safe KnobsYes
Mix or Match Component CapabilityYes
Cooktop Burner Type2 Sealed, 10,000 BTU
Valves (Degree of Turn)270
Downdraft Exhaust (CFM)400
Optional Blower Mount CapabilitiesBack or Straight Down
Variable Speed Fan3 Speeds - Hi/Med/Low
Accepts ModulesLeft Side Only
LP ConvertibleYes, Kit Included
Fuel TypeNatural Gas
StyleDowndraft
Gas Grill Module (sold separately)JXGG90L (left side only)
Griddle Module (sold separately)JXGL90L (left side only, requires grill module (JXGG90L) to operate)
Control LocationUpfront
Component StyleDowndraft Vent
Ignition SystemElectronic
Two Burner Gas Module (right side included)JXGB90B (left side sold separately)
Cooktop SurfaceDeep Porcelain-Enamel
Control TypeInfinite Heat Rotary
Space Required Below Cooktop6 in
Cooktop Burner Grate FeaturesDishwasher Safe
ConfigurationDual Modular - Both sides accept optional modules
Cooktop Burner Grate FeaturesContinuous Grates

POWER / RATINGS

Burner BTU Ratings (000's/BTU) - LP Gas(1) 9.1
Griddle BTU Rating (000's/BTU) - LP Gas(1) 9.1
Grill BTU Rating (000's/BTU) - LP Gas(1) 9.1
Grill BTU Rating (000's/BTU) - Natural Gas(1) 10.0
Burner BTU Ratings (000's/BTU) - Natural Gas(1) 10.0
Griddle BTU Rating (000's/BTU) - Natural Gas(1) 10.0
Volts/Hertz/Amps120v; 60Hz; 15A

WARRANTY

Parts WarrantyLimited 1-year entire appliance
Warranty NotesSee written warranty for full details
Labor WarrantyLimited 1-year entire appliance
Warranty NotesFor models produced on or after January 1, 2006

ACCESSORIES

LP Conversion KitIncluded

APPEARANCE

Color AppearanceBlack on Black
Cooktop Burner Grate ColorBlack Gloss
Control Panel ColorBlack

Dimensions & Weight

Width30 in.
Height18.5 in.
Length21.75 in.
Weight64 lbs.

Number of Boxes, Shipping Dimensions, & Shipping Weight

Number of Boxes1
Shipping Width35 in.
Shipping Height23.5 in.
Shipping Length26.75 in.
Shipping Weight104 lbs.
Total of Shipping Weight104 lbs.
SourceCalculation

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement6.99 ft³
Dimensional Weight86.84 lbs.
Total of Cubes6.99 ft³
Total of Dimensional Weight86.84 lbs.
